Obsidian Control Systems NX1-16 Lighting Controller with Bag Package
SKU #: NX1-16-NCASE
Reg.
$4,742.94
Now
$4,490.40
Reg.
In Stock - Ships in 3-5 Days
Most orders placed by 3pm ET ship in 3-5 business days
The NX1-16 is the essential lighting controller in the innovative and powerful ONYX platform. Fully featured and unrestricted if offers the complete ONYX experience without compromises in an ultra-compact package. Utilizing the full ONYX Operating System the NX1-16 includes a high-brightness 10.1" HD multi-touch screen; 4 assignable parameter encoders; 10 full motorized playbacks with four freely assignable buttons plus and extra playback and function key hybrid array. A dedicated Master Go section rounds out the efficient front panel design. Including the latest in industrial components the NX1-16 contains a powerful Intel processor, high speed NVMe SSD drive and 16GB of DDR5 RAM, allowing fast boot times, instant operation and the ability to process 16 Universes right inside the console.
With four DMX ports, dual Gigabit network ports for up to 16 Universes of Art-Net, sACN plus the ONYX X-Net protocol the NX1-16 has ample connectivity and power for a wide variety of shows and applications. One additional touch monitor is supported for even more direct access at anytime. The NX1-16 is further expandable with the dedicated NXK keypad and the NXP motorized playback wing. A simple magnetic alignment system allows attachment on either side of the NX1-16. The keypad and playback wing are part of the ONYX platform and can be utilized with all other NX devices or ONYX on any PC system.
Obsidian Control Systems NX1-16 Lighting Controller Features:
- Portable and compact fully featured lighting console.
- 10.1" Full HD multi touch screen, 1x external touch display.
- ONYX License (16 Universes).
- Fully integrated industrial processing.
- 10 Motorized Playbacks, 10 Playback / Function Hybrids, 4 Encoders, Master Go section.
Obsidian Control Systems NX1-16 Product Specifications:
Surface:
10x 60 mm motorized playback faders, each with 4x function-assignable buttons
10x customizable playback or multi-function keys
Playback Select button
Master Go section with Go, Pause, Snap and Release
4x digital rotary encoders with push function and status LED for fixture parameter control
Virtual Keypad control
Hardware:
Industrial 10.1" TFT 16:9 touchscreen (1920x1200px)
500 GB NVMe M.2 storage drive
Industrial motherboard with Intel CPU
Quiet thermal design using advanced copper heat pipe coolers
16 GB DDR5 RAM
Intel UHD graphics processor
Windows IoT Embedded Operating System
OS installation by USB 3.0 storage device
Supports Windows USB touchscreens
Connections:
4x DMX / RDM Universe In/Out: 5pin locking XLR
External Display: 1x HDMI
Network: 2x Gigabit RJ45 Ethernet for Art-Net, sACN and ONYX X-Net
Storage and Peripherals: 2x USB 3.2, 2x USB 2.0
Audio Out, Mic In: 2x 3.5mm Jack
Desk Lamp: USB 5V
IP65 Locking Power In
General Specifications:
Length: 298.5 mm (11.75 in.)
Width: 636 mm (25 in.)
Height: 71 mm (2.8 in.)
Weight: 8.1kg (17.8 lbs.)
100-240V 50/60 Hz, 104W
This Package Includes:
(1) Obsidian Control Systems NX1-16 Lighting Controller
(1) LED USB desk lamp
(1) Dust Cover
(1) USB 3.0 recovery drive
(1) IP65 Locking power cable
(1) Properly Fitting & Durable Protective Transport Case
(4) ProX XC-5PDMX25 High Performance 25' 5PIN DMX Cables
(5) 8" Reusable Hook and Loop Cable Ties
