Electro-Voice ELX200-18SP 18" Powered Subwoofer

SKU
ELX200-18SP-US
$1,199.00
In Stock & Ready to Ship

Most orders placed by 2pm ET ship the same day (business days only).

Best Price + Plus
Check In-Store Availability

Free Shipping on most orders with minimum purchase of $50 or more for a limited time.

Ground shipments only in the lower 48 contiguous United States.

Excludes oversized or overweight items such as oversized speakers, oversized cases, trussing and staging. Other exclusions include some fluids, some parts and special orders.

Any questions, please call 1-800-355-7746 during normal business hours.

Offer subject to change or termination without notice. Not responsible for typographical errors.

The lowest price is not always the best price. When you shop with us, you can always expect to get our BestPrice+Plus guaranteed.

Learn More

1 800 355 7746



I DJ NOW - Babylon, NY store (Pick Up In Store Only)
Mon - Sat 10am - 8pm
Sun 11am - 5:00pm
631 321 1700



I DJ NOW - Queens, NY Store (Pick Up In Store Only)
Mon - Fri 10am - 9pm
Sat 10am - 7pm
Sun 12 noon - 6pm
718 762 0100

ELX200-18SP features high-efficiency Class-D power amplifiers (up to 1200 W) with integrated QuickSmartDSP, and delivers up to 132 dB SPL utilizing transducers designed and engineered by EV (18-inch EVS-18L woofer). Powered subwoofer models allow easy setup via three presets (Music, Live, Club), sub/top system-match crossovers, three-band EQ, five user-programmable presets (Store and Recall settings), visual monitoring of limiter status, input level control and meters, and master volume control to ensure optimal gain structure. ELX200 powered models are ideal for portable and installed applications, with lightweight and compact 15-mm wood enclosures, integrated M20 threaded pole polemount plate, and two-handle design for easy lifting. The new QuickSmart Mobile wireless control and monitoring application, using Bluetooth Low Energy (BTLE) technology, allows intuitive system control, configuration and monitoring of up to six powered ELX200 loudspeakers simultaneously. Receive alerts when your system is being overdriven, and control your system while in front of your speakers, not behind. Bluetooth is available in select countries.

Wireless control and monitoring via the new Bluetooth QuickSmartMobile App* Control your sound while in front of your system. Quickly configure up to six ELX200 loudspeakers simultaneously, and receive immediate notification during critical performance conditions. Perfect for both portable and installed applications. Next-generation enclosures offer a step up in both styling and build quality. Full-range models feature lightweight, compact composite enclosures with internal reinforcement, designed to minimize resonance and increase rigidity and strength. With the lightest 18-inch wood powered sub on the market, and a stunning 10-inch top / 12-inch sub compact combo available to serve smaller venues, there are options available for every application. Professional-grade hardware includes three M10 threaded suspension points for forged eyebolts, integrated pole-mounts, and our proven three-handle design for easy lifting. Heavyweight performance in a lightweight package. Though ELX200 is easy to carry, its tough construction and components ensure legendary EV durability and sound quality, night after night. System reliability is verified with over 500 hours of abuse and endurance testing - far above and beyond industry norms. Super-efficient Class-D power amplifiers deliver distortion-free maximum SPLs utilizing high-sensitivity transducers - all designed and engineered by Electro-Voice. QuickSmartDSP provides best-in-class processing via EV's signature single-knob user interface with LCD. Easy setup via four presets (Music, Live, Speech, Club), three-band EQ, five user-programmable presets, sub/top system-match crossovers, input level control and metering, and master volume control to optimize gain structure. Electro-Voice-patented SST (Signal Synchronized Transducer) waveguide design combines a more compact footprint with enhanced acoustic performance. The design allows for a larger waveguide, which is placed forward in the enclosure to time-align the woofer and the tweeter, providing exceptionally precise and consistent coverage - all with deeper, tighter bass response.
* Bluetooth is available in select countries.
**All are available in powered and passive versions.

Electro-Voice ELX200-18SP Features:

  • EV QuickSmart Mobile application: quickly and wirelessly configure, control and monitor up to six ELX200 loudspeakers simultaneously, and receive immediate notification during critical performance conditions. Bluetooth is available in select countries.
  • QuickSmartDSP features best-in-class processing. Easy setup via three presets, sub/top system-match, five user-programmable presets, visual monitoring of limiter status, input level control and meters, and master volume control to optimize gain structure, all via LCD.
  • High-efficiency 1200 W Class-D power amplifier delivers up to 129 dB peak SPL utilizing ultraefficient, high-sensitivity transducer designed and engineered by EV.
  • System reliability verified with over 500 hours of abuse and endurance testing.
  • Ideal for portable and installed applications. Professional-grade hardware: integrated M20 threaded pole mount plate and two-handle design for easy lifting.

Electro-Voice ELX200-18SP Specifications:
Available ColorBlack
Connector Type(2) XLR/TRS combo jacks and (2) XLR link outputs
Depth574 mm / 22.5"
Enclosure Material15 mm plywood with EVCoat
FamilyELX200
Frequency Range (-10 dB)40 Hz – 145 Hz
Frequency Response (-3 dB)47 Hz – 105 Hz Hz
Grill18 AWG steel with powdercoat
Height600 mm / 23.3"
LF TransducerEVS-18L 457 mm (18 in)
Low Pass FrequencyAdjustable: 80 Hz, 100 Hz, 120 Hz, 150 Hz
Max. SPL/1m (calc)132 dB
Power Consumption100 - 240 V~, 50 - 60 Hz, 1.8A
Power Rating1200 W
Powered or PassivePowered
Shipping Weight33.1 kg / 73 lbs.
Speaker TypeSubwoofer
Weight Net29 kg / 64 lbs.
Width507 mm / 20"
Woofer Size18 inch

Each ELX200-18SP Retail Box Includes:
(1) Electro-Voice ELX200-18SP 18" Powered Subwoofer
(1) IEC Power Cord
(1) Owners Manual

Ratings & Reviews

Be the first to review this product
