Elation Professional Fuse SFX Specifications:
Source
300W 6,800K Bright White LED Engine
20,000 Hour Average LED Life
Test lab conditions. May vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
Photometric Data
12,000+ Total Lumen Output
CRI 70
Effects
4.5° - 38° Motorized Zoom
Remote Focus
Variable Frost Filter
Dual Independent Prisms for Layering
Motorized Iris
Variable 16-bit Dimming Curve Modes
High Speed Electronic Shutter and Strobe
Color
CMY Variable Color Mix
7 Position Color Wheel
Gobos
2 Gobo Wheels
Wheel #1 with 8 Rotating / Interchangeable Glass Gobos
Wheel #2 with 10 Static Gobos
Control / Connections
31 DMX Channels
16-bit Pan, Tilt, and Dimming Control
DMX Adjustable LED Frequency
DMX, RDM, E-FLY Wireless, Art-Net, sACN Protocol Support
4 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
Locking 5pin XLR Connector In/Out
Locking RJ45 Ethernet Connector In/Out
IP65 Locking Power Connector In/Out
USB Connection (Firmware Updates)
With Wired Digital Communication Network
Size / Weight
Length: 14.6" (370mm)
Width: 10.1" (230mm)
Vertical Height: 23.41" (594.5mm)
Weight: 46.3 lbs. (19.3kg)
Electrical
AC 100-240V - 50/60Hz
432W Max Power Consumption
14°F to 113°F (-10°C to 45°C)
Approvals / Ratings
CE | cETLus (pending) | IP20
Each Fuse SFX Retail Box Includes:
(1) Elation Professional Fuse SFX LED Spot FX Multi-Purpose Luminaire Fixture
