ADJ DS4HC Horizontal Panel Connector for DS4 LED Video Panels

The ADJ DS4HC is a Horizontal panel connector for DS4 LED video panel set ups.

Offering a pixel pitch of 4.8mm, the Design Series panels utilize 3-in-1 SMD2020 LEDs to generate a brightness of 1200 NITS. The square panel has a pixel density of 104 x 104, which is equivalent to 43,264 per square meter, and the others have an equivalent density applied to their specific shapes and sizes. The panels have a recommended minimum viewing distance of 12.5ft. (3.8m) as well as a wide viewing angle of 160-degrees (horizontal) and 120-degrees (vertical), making them ideal for a wide variety of applications.

The Design Series panels are designed for both fixed installations and one-off/touring productions and feature a cleverly conceived locking system that makes it easy to join together multiple panels into screens of all shapes and sizes. Each panel is fitted with retractable plastic locking bars on their top and left sides, which slide into matching holes on the bottom and right sides of neighboring panels. A quarter turn on the end of each bar then locks the panels securely in place, while the process is quick and easy to reverse to break apart the screen for transport and storage.

To further speed up setup and pack-down, each panel is fitted with locking powerCON power cords and etherCON signal sockets on one side and matching trailing cables on the other. These are long enough to reach the corresponding sockets on neighboring panels, which has two advantages over systems that feature sockets for both inputs and outputs. First, setting up and dismantling a screen is made quicker, as only half the number of sockets need to be connected/removed and there is no need to coil and pack away loose cords. Second, it is not necessary for owners to purchase power and data cables separately, which will amount to a significant saving for those investing in a sizeable Design Series setup.

The Design Series panels are also extremely lightweight, which further adds to their flexibility and portability. The DS4 (Square) unit is only 12 lbs. (5.5 kgs), while the other smaller panels weigh even less.
