Mackie Onyx Producer 2•2 Specifications:
| Frequency Response |
| At minimum gain, +4 dBu / -6 dBFS input: | |
| All inputs: | ±0.5 dB, 20 Hz - 20 kHz |
| All outputs: | ±0.5 dB, 20 Hz - 20 kHz |
| Noise Characteristics (RMS, 10 Hz - 22 kHz) |
| Mic inputs: | <-100 dBFS |
| Line inputs: | <-100 dBFS |
| Instrument input: | <-100 dBFS |
| Line outputs, balanced: | <-85 dBu |
| Headphone outputs: | <-75 dBu |
| Distortion (THD+N) |
| +4 dBu / -6 dBFS, 1 kHz input, minimum gain | |
| Mic input: | <0.001% |
| Line input: | <0.005% |
| Instrument input: | <0.005% |
| Line outputs, balanced: | <0.001% |
| Headphone outputs: | <0.002% |
| Maximum Levels (before clipping) |
| Mic input, gain at minimum: | +11 dBu |
| Line input, gain at minimum: | +24 dBu |
| Instrument input, gain at minimum: | +24 dBu |
| Line outputs, volume at maximum: | +10 dBu |
| Headphone outputs, volume at maximum: | +10 dBu |
| Input Type |
| Input Type: | Female XLR balanced / unbalanced Female 1/4" balanced / unbalanced MIDI |
| Output Type |
| Output Type: | Female 1/4" balanced / unbalanced MIDI |
| USB |
| Format: | USB 2.0, 24-bit, 192 kHz |
| Power Requirements |
| USB Bus Powered: | High-power device (5V, up to 500mA) |
| Physical Dimensions and Weight |
| Shipping: | Packed and shipped with TLC from idjnow HQ, Ronkonkoma, NY. |
| Height: | 2.0" / 51 mm |
| Width: | 7.4" / 188 mm |
| Depth: | 4.5" / 114 mm |
| Weight: | 1.4 lb / 0.6 kg |
