FBT Pro Vertus CLA 208SA Dual 8” Powered Subwoofer
About This Product
FBT Pro Vertus CLA 208SA Dual 8” Powered SubwooferVertus CLA was created with the thought of integrating professional line array technology in an extremely compact and elegant speaker column. Compared to the traditional two-way speakers, the sound is distributed much more evenly throughout the audience, both in outdoor and in indoor environments acoustically difficult or reverberating as well. The CLA cylindrical wave front boasts the pleasant effect of present and precise forwardly projected sound. Even acoustic feedback towards microphones is reduced. Vertus CLA is a light and compact modular line array system created for both live and fixed installations, comprised by two products:
• CLA 604A: bi-amp two-way active column speakers 400 + 100W RMS
• CLA 208SA: active subwoofer 600W RMS
CLA 208SA is a 2 x 8” active subwoofer in bass-reflex design and birch ply enclosure. The internal Class D amplifier delivers 600W and is matched with a switch mode power supply and a DSP processor with filtering functions, equalization and speaker protection. Created with the idea of extending the CLA608A’s low frequency performance in live applications, the CLA208SA serves as the base support for the CLA604A column speaker which can either be frontally mounted to the sub, as well as fixed upon the optional stand through the M20 socket on the upside of the sub. The CLA208SA subwoofers are modular as well, and they can be stacked to enlarge and increase the maximum SPL.
Vertus CLA208Sa Features:• High-level sound quality from 50Hz to 20kHz expressly developed for live performance.
• Long distance sound projection and better SPL distribution towards the audience.
• Great and dynamic power performance thanks to tri-amplification system.
• Lightweight and easy to carry.
• Design and elegance for an easy integration even in the most demanding installations.
• Very compact dimensions enable the listener to concentrate on sound and not on speakers!
• High horizontal dispersion
FBT Pro Vertus CLA208Sa Specifications
• Active subwoofer in bass-reflex design
• 2 x 200 mm (8”) custom neodymium, high-excursion woofer with 50 mm (2”) voice coil
• 50Hz to 180Hz frequency response
• Class D 600W RMS amplifier with switch mode power supply
• DSP processor with 4 available presets
• Control panel with combo XLR/Jack stereo input and link, XLR Hi-pass out stereo, volume, presets, 0°-180° phase switch, status LED
• Neutrik POWERCONN input and link
• 15 mm birch plywood enclosure with anti-scratch paint finish, stackable
• M20 stand adapter, 2 integrated handles, front hardware to sustain CLA604A modules
• Extruded - aluminum power coated cabinets. Superior latching system enables the extension of the length of the line array by adding CLA604A modules for increased modularity of the system
The FBT Pro Vertus CLA208Sa Box Includes:
(1) FBT Pro Vertus CLA208Sa 2x 8” Powered Subwoofer
(1) Neutrik PowerCon Power Cord
(1) User Manual
