(2) KRK V4 S8 V Series 2-Way 8" Powered Reference Monitors Package
About This Product
KRK V4 S8 V Series 2-Way 8" Powered Reference Monitor (each)
KRK Systems V Series 8 nearfield studio monitors are specifically designed for audio production applications where accurate reproduction is critical. KRK worked with hundreds of pro engineers/producers/mixers to develop these groundbreaking monitors. Recording and broadcast studios as well as sound design and audio production houses will benefit from adding the V Series 8 as the go to monitor of choice.
V-Series 8 includes 49 user selectable EQ settings to ensure proper setup for room acoustics and placement anomalies as well as taste and individual preference. The KRK design team has painstakingly modeled and analyzed hundreds of monitor placement and room acoustic situations to ensure that KRK delivers the most useful tools with minimal adjustments.
- KRK custom designed Kevlar tweeter.
- KRK custom designed Woven Kevlar woofer.
- Optimized front ported bass reflex enclosure design.
- Bi-amped Class-D amplification.
- Acoustic and desk loading condition correction Low Frequency EQ.
- Mid and High Frequency EQ.
- Precise input level attenuation switch.
- Standby, ground lift, input sensitivity, and logo LED selectors.
- Optional protective grille included for mobile broadcast applications.
- Friction lock, Neutrik combo (XLR and TRS) connector.
- Robust EVA foam pad for non-skid and acoustic isolation.
- Universal threaded mounting bracket points.
LD Systems VIBZ 6 D 6 Channel Mixing Console with DFX
The VIBZ 6 is a compact 6-channel mixer which is perfectly suited to entertainers, small bands, home recording and installations. It features two balanced microphone inputs with high quality preamps, phantom power and 3-band EQ with +/-15 dB adjustment scope, two stereo line inputs with 2-band EQ, which are mono-compatible, and an effects loop.
The master section of the VIBZ 6 is equipped with adjustable monitor outputs, a headphone jack and 16 digital effects presets, which are foot-switchable. The mixer also has inputs and outputs for recording and playback devices, is extremely easy to use and offers a warm differentiated sound. The external power supply can be screwed on tightly.
A foot switch for the effects section and an adapter for mounting the VIBZ 6 on microphone stands are available as accessories.
- Configuration: 2-Way
- System type: Active Studio Monitor
- Low-Frequency: Woofer, 8" cast aluminum frame, Kevlar cone, ferrite magnet
- High-Frequency: Tweeter, 1", Kevlar dome, ferrite magnet
- Frequency Response: 35Hz - 19kHz
- Frequency Range: 29Hz - 24kHz
- Max Peak SPL: 118 dBSPL
- Power Output: LF (200 Watts), HF (30 Watts), Total (230 Watts)
- High Control: H1 (High Shelf -2dB 10kHz, H2 (High Shelf -1dB 10kHz / High Mid Peq -1dB 3.5kHz), H3 (High Mid Peq -1dB 3.5kHz), H4 (Flat), H5 (High Mid Peq +1dB 3.5kHz), H6 (High Shelf +1dB 10kHz / High Mid Peq +1dB 3.5kHz, H7 (High Shelf +2dB 10kHz)
- Low Control:L1 (Low Shelf -3dB 75Hz), L2 (Low Shelf -1.5dB 75Hz), L3 (Low Shelf -2dB 75Hz / Low Mid Peq -2dB 200Hz), L4 (Flat), L5 (Low Mid Peq -2dB 200Hz), L6 (Low Shelf +1.5dB 75Hz), L7 (Low Shelf +3dB 75Hz)
- Enclosure Construction: MDF / Aluminum
- Grille: Included
- Dimensions (H x W x D): 17.13" (435mm) x 11.18" (284mm) x 13.66" (347mm)
- Weight: 31.75 Lbs. (14.4 Kg.)
LD Systems VIBZ 6 D Specifications
|Mono Mic and Line Input Channels:||2|
|Mono Mic input connectors:||6.3 mm TRS, XLR|
|Mono Mic Input Type:||electronically balanced|
|Mono Mic Input Frequency Range:||10Hz|
|Amplification Range mono Mic Input:||0 - 50dB|
|Mono Mic Input Input THD-N:||0.0058%|
|Mono Mic Input Impedance:||4kOhm(s)|
|Mono Line Input Type:||electronically balanced|
|Mono Line Input Frequency Range:||10Hz|
|Amplification Range mono Line Input:||0 - 50dB|
|Mono Line Input Input THD-N:||0.0045 %|
|Mono Line Input Impedance:||21kOhm(s)|
|Mono Line Input S/N Ratio:||116dB|
|Mono Channel Equalizer High:||+/- 15 dB @ 12000 Hz|
|Mono Channel Equalizer Low:||+/- 15 dB @ 80 Hz|
|Controls Mono Mic and Line Input Channels:||Gain, 3-band EQ (High, Mid, Low), pan, AUX (DFX) Post, Channel Volume|
|Phantom power:||48 V DC switchable|
|Stereo Line Input Channels:||2|
|Stereo Line Input Connectors:||6.3 mm TS|
|Stereo Line Input Type:||unbalanced|
|Stereo Line Input Frequency Range:||10 - 54000Hz|
|Stereo Line Input Input THD-N:||0.0045 %|
|Stereo Line Input Impedance:||3,7kOhm(s)|
|Stereo Line Input S/N Ratio:||116dB|
|Stereo channel equalizer treble:||+/- 15 dB @ 12000 Hz|
|Stereo channel equalizer bass:||+/- 15 dB @ 80 Hz|
|Controls Stereo Line Input Channels:||2-band EQ (High,Low), Channel Volume, AUX (DFX) Post, Balance|
|AUX / Effects Send Channels:||1|
|AUX / Effects Send Connectors:||6.3 mm stereo jack unbalanced|
|Stereo AUX Return Channels:||1 x stereo|
|Stereo AUX Return Connectors:||2 x 6.3 mm TRS|
|Stereo Tape Out Channel:||1 x stereo|
|Stereo Tape Out Connectors:||2 x RCA (Cinch)|
|Stereo Tape In Channel:||1 x stereo|
|Stereo Tape In Connenctors:||2 x RCA (Cinch)|
|Unbalanced stereo Main Outputs:||1|
|Unbalanced stereo Main Output Connections:||6.3 mm TRS|
|Unbalanced Stereo Main Out Impedance:||120Ohm(s)|
|Max. Unbalanced Stereo Main Out Level:||+20dBu|
|Stereo Control Room Out:||1|
|Stereo Control Room Out Connectors:||6.3 mm stereo jack unbalanced|
|Headphones outputs:||6.3 mm TRS|
|Digital Effects Processor:||Yes, 24-bit AD/DA Resolution|
|Number of Presets:||16|
|Footswitch Connector DFX Mute:||6.3 mm TRS|
|Main section controls:||Master Volume, 2-track Assignment (Main, Contr. Room), Phones / Control Room Volume, Stereo Return Volume, Phantom Power, DFX Mute Schalter, DFX Presets, 2-track In Volume, DFX To Main Volume|
|Indicators:||Channel Peak, Power, DFX Peak / Mute, 4-segment Level Meter, Phantom Power|
|Operating voltage:||18 V AC - 1 A, External PSU|
|Width:||209mm / 8.2"|
|Height:||68mm / 2.7"|
|Depth:||260mm / 10.2|
|Weight:||1.45kg / 3.2 lb.|
(2) KRK V4 S8 V Series 2-Way 8" Powered Reference Monitors
(1) LD Systems VIBZ 6 D 6 Channel Mixing Console with DFX
Each V4 S8 Box Includes:
(1) KRK V4 S8 V Series 2-Way 8" Powered Reference Monitor (each)
(1) IEC power cord
(1) Removable front grill cover
(1) User manual & warranty information card
The VIBZ 6 D Box Includes:
(1) LD Systems VIBZ 6 D 6 Channel Mixing Console with DFX
(1) Power cable
(1) User manual
